Lowest Profile Steel Vises
VE-N series

Wide Space machining created Low-Height Steel Vises with the Yellow Body

VE-N seriesズーム

VE-N series

  • High rigid steel body
  • Ultra-low height type adopted, offering the maximum machining area
  • Firm gripping of work ensured by the high jaws
  • Stable clamping force secured by the mechanical enhancement toggle mechanism
  • Minimum lift up, offering the stable machining accuracy
  • Parallel use as standard
  • There is also VE125N-15 available where the guide block is located at the centre of the body.

Note 1: Please refer to the clamping force setting section of the instruction manual for the clamping range and setting method for each type.


Note 2: Please watch the video of the boosting mechanism. Click the image below to play the video.


Download Catalogue pages (PDF)
Download instruction manual (PDF)

Product Specifications

ModelVE100NVE125NVE125N-15VE160NVE200N
Jaw Width (mm) 100 125 125 160 200
Jaw Height (mm) 40 50 50 60 70
Jaw Stroke (mm) 128 204 204 274 303
Work mounting Face Height (mm) 75 85 85 100 110
Total Height (mm) 115 135 135 160 180
Total Width (mm) 109 135 135 170 214
Total Length (mm) 355 455 455 555 605
Guide Block Width (mm) 14h7 18h7 18h7 18h7 18h7
Max. Clamping Force (kN) 25 30 30 45 45
Net Weight (kg) 19 35 35 62 95
Outline Drawing2DPDF
DXF
DWG
3DParasolid
STEP

Note 1) VE125N-15 just fits to the centre groove machine table.

Note 2) Each 3D data includes two types of the positions of the jaw for both Parasolid and STEP: open end (O), closed end (C).
